An Optical Loss Test Set used to test power, insertion loss, continuity and faults on multimode fiber optic systems at 850 / 1300 nm. In a small package, it provides a powerful solution to improve test flexibility and productivity.

The 650 nm VFL Visitester feature mixes a VFL in with the test signal during Autotest. In addition to operating as a typical VFL, it gives positive visual identification of a fiber to be connected for loss testing.

Features

• Easy to use, slim, rugged & versatile

• EF compliant multimode sources

• Excellent source stability

• Large clear LCD is sunlight readable & backlit

• Large memory with Text Tag & time stamp

• One button memory dump to USB key

• KITS™ reporting software for acquisition and reporting

• Autotest power meter

• 1 % accuracy & 31 calibrated λ, ISO/IEC 17025 traceable

• Interchangeable connectors with dust cap & tilt bail

• Multi-Fiber ID Test tone generator / detector

• Long alkaline battery life with micro USB external power / charger

• Made in Australia
