A simple and reliable optical power meter with a large area 5 mm Ge detector for testing power and loss on fiber optic systems or free-space light beams up to +10 dBm. Ideal for: Plastic fiber, PCS, single mode, multimode, multi-fiber ribbon cable such as MMC, MPO 12 – 72 fiber up to 12 fibers wide, and LC/ SC etc fibeA simple and reliable optical power meter with a large area 5 mm Ge detector for testing power and loss on fiber optic systems or free-space light beams up to +10 dBm. Ideal for: Plastic fiber, PCS, single mode, multimode, multi-fiber ribbon cable such as MMC, MPO 12 – 72 fiber up to 12 fibers wide, and LC/ SC etc fiber optic systems. This versatile meter is a popular MPO tester, providing high accuracy and simplicity of use. For all fiber optic Ethernet & Infiniband applications except 16 x 1 or 16 x 2 ribbon types.
Optional connector adapter not included, order separately.r optic systems. This versatile meter is a popular MPO tester, providing high accuracy and simplicity of use. For all fiber optic Ethernet & Infiniband applications except 16 x 1 or 16 x 2 ribbon types.
Optional connector adapter not included, order separately.

Features

• 12 calibration λ, ±2% accuracy, ISO/IEC 17025 traceable

• Small size, easy to use, rugged & reliable

• dBm / dB / linear, 0.01 dB resolution

• Display hold & max/min recording

• Tone detector with Multi-Fiber ID

• Large area detector for MPO applications

• Easy to use TamperLock mode

• Interchangeable connectors

• Full QA reports

• Made in Australia
