An optical power meter for professional installers and contractors, to test power, loss and continuity on plastic fiber, multimode + single mode fiber optic systems with MPO and other connectors, and free-space beams up to +15 dBm. Ideal for: Plastic fiber, PCS, single mode, multimode, multi-fiber ribbon cable such as MMC, MPO 12 – 72 fiber up to 12 fibers wide, and LC/ SC etc fiber optic systems. This full-feature instrument has comprehensive report generation capabilities and a variety of useful features for maximum productivity and flexibility. For all fiber optic Ethernet & Infiniband applications exccept 16 x 1 or 16 x 2 ribbon types.

Optional connector adapter not included, order separately.

Features

• Easy to use, rugged & versatile

• 31 calibration λ, 1% accuracy ISO/IEC 17025 traceable

• Improved high power accuracy

• Autotest with up to 3 λ displayed

• Long battery life & micro USB external power

• Large back-lit LCD, sunlight readable

• Interchangeable connectors

• Large memory with text naming & time stamp

• KITS™ reporting software with data security

• One button memory dump to USB key

• MultiFiber ID tone detection

• Full QA & linearity test report
