Broad wavelength spectrum
InGaAs: 830nm to 1700nm
Silicon: 400nm to 1100nm

Measurement range
InGaAs: +6dBm to -72dBm
Silicon: +3dBm to -65dBm

Relative accuracy of 0.02dB*

Measurement display resolution down to 0.001dB

Fast data acquisition rate without compromising measurement accuracy

Variable sampling rate via software

Integrated temperature monitoring eliminates the need for an additional temperature sensor during long term stability tests

* Loss less than 10dB
